Flow rate up to 28 m³/h

Head up to 69 m

Operation Conditions

household industry municipal

Liquid temperature between -20℃ ~ 104℃

Ambient temperature up to + 50℃

Max pressure up to10 bar

Max suction head: No self- priming

Max inlet pressure is limited by the max

operating pressure.

Application

Air- conditioning system

Water treatment

Pressure boosting for the water on processing line

Heating and cooling water on industrial processing line

Air freshen,moistening equipment ( soft water )

Water supply and pressure boosting (drinking water)

Fertilization/ metering system

Aquaculture

Convey thin, clean, non- flammable and non- explosive

liquid without solid granules and flbers

Guide For Model Selection

Request for the flow and pressure.

The mechanical seal configurations is selective for

normal water, pure water or hot water type.

Applied region’s voltage and frequency: single- phase:

220- 240V/ 50Hz; 220V- 240V/ 60Hz; 110- 120V/

60Hz is available; Three- phase: 380- 415V/ 50Hz;

380- 415V/ 60Hz is available.

Applied region’s request for safety certificate. Confirm

the bore of outlet and inlet.

Plug’s type and length ( no plug, Chinese plug, Europe

plug, UL plug … is available)
